Tissue Production Line Should Include Tissue Cutting Folding Packing Machines

Tissue production line should include tissue cutting folding packing machines

Zhejiang Onepaper Smart Equipment Co., Ltd.

Official wesite: https://onepapergroup.com

Whatsapp/WeChat: +86-18815151008

---------------------

When it comes to tissue production, you have a lot of options to choose from. There are many different types of tissue production machines that you can use to produce a variety of products. The type of tissue production machine that you should use is tissue cutting folding packing machines. These machines are crucial in making sure that the tissue that is produced is durable and long lasting.


Tissue Production Line Should Include Tissue Cutting Folding Packing Machines


However, there are many ways to create tissue. If you have tissue cutting folding packing machine, you will produce more tissue in a shorter period of time. This machine can cut and fold tissue, and it can pack the tissue into bags.


Machine Features:

Facial tissue making machine working flow: The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders, and then interfolded into inter overlapped rectangular facial tissue sheets.

This machine adopts independent servo motor drive, and automatic paper tension control automatic marking functings. It features of high speed, nice folding and easy operation.

1. Can order steel to rubber embossing rolls, pneumatically separated.

2. Wallboard rack and Machine running stability and extremely good and fast.

3. Pneumatic jumbo roll loading, pneumatic paper driving,stepless speed additionstment, and web tension control.

4. Equipped with roots type vacuum pump for stable running of the machine.

5. Make various products width as requirement.

6. Equipped with edge embossing unit to keep the plise together.

7. The machine will stop when the paper broken. It avoid waste caused by no paper or paper broken.

8. The web can be threaded on the machine by the two jog buttons, It's more safer and easier to thread the web.


Specification of Facial Tissue Folding Machine:

Machine Model: CS-190/6L (Other size to be specified)

Finished Products Unfolded Size: 95x(120-210)x2mm

Folding Products Size: 190x(120-210)x2mm

Raw Material Width: 1260mm

Raw Material Diameter: 1200mm

Raw Material Core Diameter: 76.2mm

Output Capacity (8 hours): 2000-3000kg

Embossing Unit: Steel to rubber

Edge Embossing: Steel to steel edge embossing, independent pneumatic regulation

Slitting Unit: Pneumatic slitting

Main Servo Moter Power: 5.5kw

Unwind Frequency Motor Power: 1.5kw (2 units)

Vacuum System: 18.5 kw Vacuum pump (Taiwan Roots blower)

Pneumatic System: 3HP air compressor,Min. pressure 5kg/cm2PA (Provider by user themselves)

Driving System: Timing belt

Dimension: 5870x2800x2207mm

Weight: About 5 tons
