Tissue Folding Machine Is Usually Seen Among A Faciall Tissue Production Line

Tissue folding machine is usually seen among a faciall tissue production line

Zhejiang Onepaper Smart Equipment Co., Ltd.

Official wesite: https://onepapergroup.com

Whatsapp/WeChat: +86-18815151008

Tissue folding machines are usually seen on a faciall tissue production line. They are used to fold tissues, and they are used in a continuous process of production.


Tissue Folding Machine Is Usually Seen Among A Faciall Tissue Production Line


To create a folded tissue, the machine will first start by unfolding the tissue to a set of flat sheets, then it will fold and secure the sheets, and finally it will press the sheets to create a desired thickness and size.


Tissues can be folded from one square to another and can also be folded in a circular shape. Tissues in a circular shape are often used for various purposes, such as for packaging.


With a tissue folding machine, it is possible to produce large amounts of a single type of tissue. The machine is usually made of steel, and it has a folding mechanism that will flatten the sheets.


Machine Features:

Facial tissue making machine working flow: The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders, and then interfolded into inter overlapped rectangular facial tissue sheets.


This machine adopts independent servo motor drive, and automatic paper tension control automatic marking functings. It featurse of high speed, nice folding and easy operation.

1. Can order steel to rubber embossing rolls, pneumatically separated.

2. Wallboard rack and Machine running stability and extremely good and fast.

3. Pneumatic jumbo roll loading, pneumatic paper driving, stepless speed additionstment, and web tension control.

4. Equipped with roots type vacuum pump for stable running of the machine.

5. Make various products width as requirement.

6. Equipped with edge embossing unit to keep the plise together.

7. The machine will stop when the paper broken. It avoid waste caused by no paper or paper broken.

8. The web can be threaded on the machine by the two jog buttons, It's more safer and easier to thread the web.


Specification of Facial Tissue Folding Machine:

Machine Model: CS-190/6L (Other size to be specified)

Finished Products Unfolded Size: 95x(120-210)x2mm

Folding Products Size: 190x(120-210)x2mm

Raw Material Width: 1260mm

Raw Material Diameter: 1200mm

Raw Material Core Diameter: 76.2mm

Output Capacity (8 hours): 2000-3000kg

Embossing Unit: Steel to rubber

Edge Embossing: Steel to steel edge embossing, independent pneumatic regulation

Slitting Unit: Pneumatic slitting

Main Servo Moter Power: 5.5kw

Unwind Frequency Motor Power: 1.5kw (2 units)

Vacuum System: 18.5 kw Vacuum pump (Taiwan Roots blower)

Pneumatic System: 3HP air compressor,Min. pressure 5kg/cm2PA (Provider by user themselves)

Driving System: Timing belt

Dimension: 5870x2800x2207mm

Weight: About 5 tons
