Facial Tissue Bundling Machine OPZ-35

This toilet roll packing machine is a device suitable for automatic packaging of toilet paper rolls; it fully automates the steps of feeding, weaving, bagging, packing, gusseting, and sealing. The working procedure of the toilet roll packing machine is automatically controlled by the PLC programming system, the parameter setting is convenient and quick, and the working time can be adjusted according to different packaging materials and volumes. It uses a new servo drive and is equipped with a 10-inch touch screen, which not only ensures efficient and smooth operation, but also visualizes the process and makes the packaging work more intelligent. In addition, this machine can also realize the free switching of packaging specifications, which is conducive to the centralized production of packaging of the same specifications according to customer requirements.

ONEPAPER

Specifications of Facial Tissue Bundling Machine OPZ-35

Item/model

OPZ-20

Packaging materials

Double-sided heat-sealing film prefabricated bags(PE/APP,etc)

Design speed

25bundlers/minute

Stable production speed

8-20bundlers/minute

Maximum packaging size specification

630X400X130(MM)

Packaging style

1-3 row, 3-7 bags each row

Package style

Bagging packaging

Power

380V 50HZ

Machine total power

13.0KW

Compressed air

0.5Mpa

Air flow

160L/minute

Machine outline dimensions

L3150mmxW1560mmxH1850mm

Machine weight

About 1500KG


Features of Facial Tissue Bundling Machine OPZ-35

01

Fully automatic packaging with high precision, high degree of automation, high efficiency and convenience with this automatic facial tissue packaging machine;

02

PLC stable control system, fast parameter setting, timely response to custom parameters, free switching between specifications;

03

The new fault self-detection system makes regional faults clear at a glance;

04

Beautiful appearance, low energy consumption, and the hanging design is easy to clean.
